TS14N3E15 Bộ đồng bộ, Synchro TS14N3E15 Tamagawa, Tamagawa Viet Nam

Model: TS14N3E15

Hãng: Tamagawa

Điện áp đầu vào: 115 V

Điện áp đầu ra: 0.783±3 % V

Tần số: 400 Hz

Dòng điện: 85 mA

Điện trở: 100(DC500 V) MΩ

Momen xoắn: 4.9×10-4(5 gfcm)

Hotline: 0933.911.903

Liên hệ với chúng tôi để có thêm thông tin và giá tốt nhất!

Synchros

	JIS Equivalent Series	NDS Equivalent Series
Temperature	-20 to +50 °C	-30 to +60 °C
Vibration	Full Amplitude 0.5 mm Vibration Frequency 10 to 55 Hz	Full Amplitude 0.75 mm , 0.50 mm , 0.25 mm Vibration Frequency 5 to 15 Hz , 16 to 25 Hz , 26 to 33 Hz
Shock	(Low Shock) The acceleration 98 m/s2 20 ms time duration	(High Shock) NDS XF 8005 Hl 1A (The acceleration 9800 m/s2)REF (2.3 ms time duration) REF

JIS(JAPANESE INDUSTRIAL STANDARD) EQUIVALENT SERIES

Model	TS14N3E15	TS14N7E15	TS486N50E11	TS486N54E11
Function	CX	CT	CX	CT
Input Voltage(Vrms)	115	90	100/110	90
Input Frequency(Hz)	400		50/60
Output Voltage or Transformation Ratio	0.783±3 %	0.735±3 %	90±3 Vrms	57.3±3 Vrms
Input Current(mA Max)	85	25	85	20
Electrical Error(minutes Max)	±18	±16
Residual Voltage(mVrms Max)	125	75	100	110
Temperature Rise(°C Max)	30
Insulation Resistance(MΩ Min)	100(DC500 V)		10(DC500 V)
Dielectric Strength(Vrms.1 min)	900		1,000
Friction Torque(Nm Max)	4.9×10-4(5 gfcm)		24.5×10-4(25 gfcm)
Mass(g)	180		570

Model	TS15N11E15	TS820N58E11	TS820N50E11	TS820N54E11
Function	CDX		TDX	TDR
Input Voltage(Vrms)	90
Input Frequency(Hz)	400	50/60
Transformation Ratio	1.154±3 %
Input Current(mA Max)	100		200
Electrical Error Receiver Error(minutes Max)	±16			TDX±16 TDR±90
Torque Grad.(Nm/deg. Max)	-		2.0×10-4(2 gfcm/deg.)
Residual Voltage(mVrms Max)	125	185	-
Temperature Rise(°C Max)	30		60
Insulation Resistance(MΩ Min)	100(DC500 V)	10(DC500 V)	-
Dielectric Strength(Vrms.1 min)	900	1,000
Friction Torque(Nm Max)	6.8×10-4(7 gfcm)	24.5×10-4(25 gfcm)	24.5×10-4(25 gfcm)	-
Mass(g)	180	570		610

Model	TS472E11	TS472N6E11	T453E11	TS453N6E11
Function	5 G	5 M	6 G	6 M
Input Voltage(Vrms)	100/110
Input Frequency(Hz)	50/60
Output Voltage(Vrms)	90±3
Input Current(A Max.)	0.6		1.2
Torque Grad.(Nm/deg. Min)	29.5×10-4(30 gfcm/deg.)		88.3×10-4(90 gfcm/deg.)
Electrical Error Receiver Error(deg. Max)	±0.5	±2.0	±0.5	±1.0
Temperature Rise(°C Max)	30
Insulation Resistance(MΩ Min)	10(DC500 V)
Dielectric Strength(Vrms.1 min)	1,500
Mass(g)	3,500 Max	2,600	6,000 Max	4,800

Model	TS866E11	TS866N6E11	TS473E11	TS473N6E11
Function	6 DG	6 DM	5 DG	5 DM
Input Voltage(Vrms)	90
Input Frequency(Hz)	50/60
Output Voltage(Vrms)	90±3
Input Current(A Max)	2.0		1.0
Torque Grad.(Nm/deg. Min)	6.87×10-3(70 gfcm/deg.)		1.57×10-3(16 gfcm/deg.)
Electrical Error Receiver Error(deg. Max)	±0.5	±1.5	±0.5	±1.5
Temperature Rise(°C Max)	30
Insulation Resistance(MΩ Min)	10(DC500 V)
Dielectric Strength(Vrms.1 min)	1,500
Mass(g)	4,800	5,200	3,500 Max	3,500 Max

	RUGGEDIZED		WATER-PROOF
Model	TS801N5E11	TS806N5E11	TS808E11
Function	TX	CX	TX
Input Voltage(Vrms)	100/110
Input Frequency(Hz)	50/60
Output Voltage(Vrms)	90±3
Input Current(A Max)	0.5		0.6
Electrical Error(minutes Max)	±60	±30	±60
Torque Grad.(Nm/deg. Min)	1.38×10-3(14 gfcm/deg.)	-	2.95×10-3(30 gfcm/deg.)
Residual Voltage(mVrms Max)	-	200	150
Temperature Rise(°C Max)	30
Friction Torque(N-m Max)	4.90×10-3(50 gfcm)		78.4×10-3(800 gfcm)
Insulation Resistance(MΩ Min)	10(DC500 V)		100(DC500 V)
Dielectric Strength(Vrms.1 min)	1,500
Mass(g)	3,000		11,000(11 kg)
